PHOENIX CONTACT QUINT4-S-ORING/12-24DC/1X40/+ REDUNDANCY MODULE 2907753

Product Description

The Phoenix Contact Quint4-S-ORING/12-24DC/1X40/+ Redundancy Module is part of the Quint Power series, designed to provide highly reliable power in critical applications that require redundancy for maximum uptime and system availability. This redundancy module allows for parallel operation of two power supplies and ensures that a failure in one supply does not cause a power interruption, thereby increasing the overall reliability of your system.

Detailed Features and Specifications:

1. Input Voltage Range:

• The module operates with a 12-24 VDC input voltage, suitable for many industrial automation, control, and power distribution systems.
• The flexibility to support both 12V and 24V allows for integration into systems with varying power requirements.

2. Output:

• Single 40A Output: The module provides a 40A output, which is designed to supply high-current requirements, ensuring that the systems requiring significant power can operate without interruptions.

3. ORing Diode Redundancy:

• The ORing redundancy feature allows for two power supplies to operate in parallel to ensure continuous power supply. If one supply fails, the other seamlessly takes over, preventing any system downtime.
• This is a key feature in critical infrastructure or automation systems, where any disruption in power could cause significant issues, including data loss, machine downtime, or even safety hazards.

4. Enhanced System Availability:

• The Quint4-S-ORING module is designed to improve the availability of your power supply system by enabling redundancy without the need for complex wiring or manual intervention.
• This configuration ensures that your industrial systems maintain operational continuity, even in the event of a fault in one of the power supplies.

5. Compact and Efficient Design:

• Despite its high current rating of 40A, the redundancy module is designed to be compact, making it easy to integrate into control panels or industrial enclosures.
• Its efficient design also helps to minimize energy loss, reducing the operational cost of powering large systems.

6. Factory Sealed:

• The module comes factory sealed, ensuring that it is new, undamaged, and ready to be integrated into your system with confidence.
• The factory-sealed packaging guarantees the product is free from defects and has passed rigorous quality control standards.

7. Built-In Protection:

• This module features protection mechanisms such as overload protection, short-circuit protection, and overvoltage protection to prevent damage to the system in case of electrical faults.
• These protection features ensure that both the redundancy module and any connected systems are safeguarded from electrical issues that could potentially damage equipment.

8. Diagnostic and Monitoring Functions:

• The module offers integrated diagnostic features that allow operators to monitor the health of the power supply system.
• With real-time status indicators, it helps detect issues like a failure in one of the power supplies or problems within the module itself.
• This early detection of problems can prevent unplanned downtime and help to quickly address faults before they escalate.

9. Temperature Range:

• The Quint4-S-ORING module is designed to operate in a wide temperature range (typically from -25C to +70C), ensuring that it works reliably in both cold and hot industrial environments.

10. Certified Quality:

• The module adheres to international safety and quality standards, including CE and UL certifications. This ensures that it meets the required safety, electromagnetic compatibility (EMC), and environmental guidelines for industrial equipment.

Applications:

• Industrial Automation: Ensures that control systems, PLCs, sensors, and other automation devices have a reliable power source without interruption.
• Critical Infrastructure: Ideal for power-sensitive industries where even a brief interruption in power could lead to significant losses or system failures.
• Robust Machine Control: Powers machines, robots, and other large systems that require consistent, high-current DC power.
• Telecommunication & Data Centers: Provides redundant power for data centers and telecommunications systems to avoid outages and data loss.
• Backup Power Systems: This redundancy module is ideal for situations where backup power is essential, ensuring that power continues without fail even in the case of a single power supply failure.

Advantages:

• Redundancy without Complexity: Allows two power supplies to work in parallel for increased system reliability, without the need for complex systems.
• Increased System Uptime: By preventing downtime through redundancy, it helps ensure continuous operation of critical systems.
• High Current Capacity: The 40A output ensures that high-power systems can be effectively supported.
• Compact and Easy Integration: Its compact size allows easy integration into control cabinets and industrial enclosures with limited space.
• Enhanced Protection: With overload, short-circuit, and overvoltage protection, the module protects sensitive equipment from electrical faults, ensuring longer operational life.

Summary:

The Phoenix Contact Quint4-S-ORING/12-24DC/1X40/+ Redundancy Module is an essential component for providing redundant power in critical industrial systems, offering a 40A output with ORing diode redundancy to ensure uninterrupted power. Its high efficiency, compact design, integrated diagnostics, and robust protection features make it ideal for demanding industrial applications where reliability and system uptime are crucial.
