TDK Lambda DLP-240-24-1/E 100-240VAC to 24VDC 10A POWER SUPPLY

Product Description

The TDK Lambda DLP-240-24-1/E is a 24V DC power supply designed for industrial and commercial applications. It provides reliable and efficient power conversion from 100-240 VAC input to 24V DC output, capable of delivering up to 10A of current, which makes it suitable for a variety of applications requiring high power output in a compact form factor.

Key Features of TDK Lambda DLP-240-24-1/E Power Supply:

1. Power Conversion:

   • Converts 100-240 VAC input voltage to a stable 24V DC output.
   • This wide input voltage range makes it compatible with different global power standards.

2. Output Power:

   • Provides a 24V DC output with a current capacity of 10A, delivering a maximum output power of 240W.
   • Suitable for powering high-power devices like industrial control systems, automation equipment, sensors, or communication devices.

3. Efficiency and Reliability:

   • The power supply features high efficiency and reliability, reducing heat generation and improving long-term operational life.
   • It offers overload protection, over-voltage protection, and short-circuit protection, ensuring safe operation in case of load anomalies or faults.

4. Compact Design:

   • The DLP-240-24-1/E is designed to fit in 1U (rack-mountable) or other compact enclosures, saving space in industrial control systems or server racks.
   • It has a low-profile design that facilitates easy integration into systems with limited space.

5. Cooling:

   • The unit is fan-cooled, which helps maintain its operation at optimal temperatures.
   • The fan is designed to be low-noise, ensuring that it doesn™t disrupt sensitive environments like laboratories or office spaces.

6. Convection Cooled Option:

   • In some configurations, the unit can operate without a fan, relying on natural convection cooling for quieter operation and applications that don't generate excessive heat.

7. Power Factor Correction (PFC):

   • The power supply is designed with active power factor correction to meet stringent energy efficiency standards.
   • It helps minimize harmonic distortion and ensure that the power supply draws clean power from the mains.

8. Safety and Compliance:

   • The DLP-240-24-1/E complies with various international safety and electromagnetic compatibility (EMC) standards, ensuring that it meets regulatory requirements for global markets.
   • UL, CE, CSA, and CB certifications are available, verifying that the product is safe for industrial use.

9. Environmental Ratings:

   • It has an operating temperature range of -20C to 70C, allowing it to be used in various industrial environments, including those with fluctuating temperatures.
   • IP20 protection rating, meaning the unit is protected against dust and direct contact but should be installed in a protected area.

10. Monitoring and Adjustments:

    • The power supply provides LED indicators to show the status of operation, including normal operation and fault conditions.
    • It is designed to be easily adjusted or monitored via external systems for ongoing performance tracking.

Specifications of TDK Lambda DLP-240-24-1/E Power Supply:

• Input Voltage Range: 100-240 VAC (wide input range for global compatibility).
• Output Voltage: 24V DC.
• Output Current: 10A (maximum).
• Output Power: 240W.
• Efficiency: Up to 90% (depending on load and operating conditions).
• Cooling Type: Fan cooling, with an option for convection cooling.
• Operating Temperature Range: -20C to 70C.
• Protection Features:
  • Overload Protection.
  • Overvoltage Protection.
  • Short-circuit Protection.
  • Thermal Shutdown.
• Power Factor Correction: Active PFC (meets international standards for reducing harmonics).
• Safety Certifications: UL, CE, CSA, CB, and others.
• Output Ripple and Noise: Typically less than 150 mV peak-to-peak.
• Mounting: Designed for rack mount or direct integration into systems.
• Size: Typically 1U form factor for compact installation.

Applications of TDK Lambda DLP-240-24-1/E:

The DLP-240-24-1/E power supply is ideal for a wide range of applications, including but not limited to:

1. Industrial Automation:

   • Powering control systems, sensors, actuators, and communication devices within industrial automation systems.

2. Telecommunication:

   • Provides power for telecom equipment, including base stations, routers, and other network devices requiring stable and reliable 24V DC power.

3. Test and Measurement Equipment:

   • Used in laboratories and testing environments to provide regulated power to sensitive equipment.

4. Networking and Data Centers:

   • Powering servers, switches, and routers, where efficient and reliable DC power conversion is crucial for the operation of IT infrastructure.

5. Medical Equipment:

   • Suitable for powering medical instruments and devices that require regulated 24V DC power while meeting safety standards.

6. Security Systems:

   • Powers surveillance systems, access control systems, and other security devices.

Advantages of TDK Lambda DLP-240-24-1/E:

1. High Power Efficiency:

   • The power supply offers high efficiency (up to 90%), minimizing power loss and heat generation, which is crucial in energy-conscious applications.

2. Compact and Space-Saving:

   • Its low-profile design makes it ideal for integration into rack-mounted or space-limited systems, such as those in industrial control cabinets or data centers.

3. Reliability and Safety:

   • The inclusion of safety features like overload, overvoltage, and short-circuit protection enhances the system's overall safety and reliability.

4. Global Compatibility:

   • With a wide 100-240 VAC input range and safety certifications, this power supply is designed to work in different geographic regions and meet international standards.

5. Noise Reduction:

   • The fan is designed for low-noise operation, making it ideal for environments that require minimal disturbance (e.g., laboratories or office settings).

Installation and Use:

1. Mounting:

   • The DLP-240-24-1/E power supply can be mounted rack-mounted in a standard 1U format, saving space and providing easy access to the power supply unit.

2. Wiring:

   • The AC input is connected to the 100-240VAC source, and the DC output is connected to the load requiring 24V DC power.

3. Configuration:

   • Once installed, check the LED indicators to ensure the unit is operating correctly.
   • If needed, adjust the output using external systems or monitoring devices to match the required voltage or current.

Conclusion:

The TDK Lambda DLP-240-24-1/E power supply is a robust, efficient, and reliable solution for powering industrial and commercial systems that require 24V DC output. Its compact design, high efficiency, and safety features make it ideal for applications such as automation,
